SR9210 Specification Model SR9210 SR9200 Standard GB/T6062, ISO4287, DIN4768, JIS B, ANSI46.1 Measurement Range Ra 0.005~16um / 0.020~629.9uinch 0.050~10um / 1.000~400.0uinch Rq 0.005~16um / 0.020~629.9uinch -- Rz 0.020~160um / 0.780~6299uinch 0.020~100.0um / 0.780~4000uinch Rt 0.020~160um / 0.780~6299uinch -- Accuracy &#8804;&#177;10% Resolution 0.001um (Reading<10um) 0.01um (10um&#8804;Reading<100um) 0.1um (Reading&#8805;100um) Display LCD Fluctuation of display value &#8804;6% Profile digital filter Filtered profile RC, PC-RC, GAUSS -- Non-filtered profile D-P -- Sensor Radius 5um 10um Material Diamond Measuring force 4mN (0.4gf) 16mN (1.6gf) Probe angle 90&#176; Vertical radius of guiding head 48mm Maximum driving stroke 17.5mm / 0.7inch Cutoff length 0.25mm, 0.8mm, 2.5mm Driving speed Measuring force Vt=0.135mm/s (Sampling Length=0.25mm) Vt=0.5mm/s (Sampling Length=0.8mm) Vt=1mm/s (Sampling Length=2.5mm) Returning Vt=1mm/s Pickup measurement range &#177;80um Evaluation length 1~5L (selectable) Metric / Imperial Conversion Auto Power off &#8730; PC interface RS-232C (not included, it is optional part) Memory 7 Groups -- Built in Li-ion battery Rechargeable Operating condition Temp. 0~50&#176;C Humidity <85%RH Dimension 140x52x48mm (5.5x2.2x1.9inch) Net weight 420g Standard Accessories Carry Case 1 Main Unit 1 Standard Sensor 1 Standard Sample Plate 1 Power Adapter 1 Operation Manual 1 Screwdriver 1 Adjustable Leg 1 Sensor Protector 1 Optional Accessories 1, RS-232C Cable & software, USB Cable & software, Bluetooth data output 2, Extension Rod 3, SRP-110 Groove stylus 4, SRP-120 Curvature Probe 5, SRS-1 Measurement Stand ---------------------------------------------------------------------------------------------------------- ¢ÍãºàʹÍÃÒ¤ÒËÃ×ÍÊͺ¶ÒÁ¢éÍÁÙÅà¾ÔèÁàµÔÁ 0922530999 , 0848744848ËÃ×Í email ( t_phuttharat@hotmail.com ) ªÓÃФèÒÊÔ¹¤éÒâ´Â¡ÒÃâ͹à§Ô¹ â´Â¨Ð·Ó¡ÒÃÊè§ÊÔ¹¤éÒã¹Çѹ¶Ñ´ä»â´ÂºÃÔ¡Òà EMS áÅШÐÊè§ Tracking NO. ãËé·Ò§ EMS ÃÍÃѺÊÔ¹¤éÒÀÒÂã¹ 2-3 ÇѹËÅѧ¡ÒèѴÊè§ »Å. ¡Ã³ÕäÁèÁÕÊÔ¹¤éÒã¹ÊµçÍ¡ÍÒ¨µéͧãªéàÇÅÒ㹡ÒÃÊÑ觫×éÍ»ÃÐÁÒ³ 45 Çѹ·Ó¡Òà ·´ÅͧãªéÊÔ¹¤éÒáÅÐÊÔ¹¤éÒäÁèµÃ§¡ÑºÃÒÂÅÐàÍÕ´äÇé ËÃ×Í äÁè¾Íã¨ã¹µÑÇÊÔ¹¤éÒ àÃÒÂÔ¹´Õ¤×¹à§Ô¹ 100% (ÀÒÂã¹ 7 Çѹ)
