Integrated Impact Device C for thin components: no cables! Wide measuring range in HLC and direct display of con verted hardness values in HB, HRC, HV, HS. For materials steel & cast steel and cold work tool steels. Simple handling and low test expenditure. Optional printer TA220S available Hardness Tester TIME TH132 Product info: Integrated Impact Device C for thin components: no cables! Wide measuring range in HLC and direct display of con verted hardness values in HB, HRC, HV, HS For materials steel & cast steel and cold work tool steels Simple handling and low test expenditure Optional printer TA220S available Measuring range: Materials: HLC Steel&cast steel: 350-960 CWT.Steel: 350-900 Materials: HB Steel&cast steel: 80-683 Materials: HRC Steel&cast steel: 20.0-69.5 CWT.Steel: 20.7-68.2 Materials: HV Steel&cast steel: 80-996 CWT.Steel: 100-941 Materials: HS Steel&cast steel: 31.9-102 Specifications: Standard Impact Device: C integrated Hardness scales: HLD, HB, HRC, HRB, HV, HS Measuring range/materials: See table above Accuracy: ±12HLC Memory: 99 average readings Output: RS232 to printer Min.Surface Roughness of Workpiece: 0.4μm(Ra) Max.Workpiece Hardness: 960HLC Min.radius of Workpiece(convex/concave): Rmin=11mm(with support rings) Min.Workpiece weight: 0.5-1.5kg on stable support, 0.02-0.5kg with compact coupling Min.Workpiece thickness coupled: 1mm Min.Thickness of hardened layers:0.2mm Indentation depth: Impact Devices data Continuous Working time: 60h Power: Recharable li-ion battery Operating temperature: 0～40℃ Overall dimensions: 155 x 24 x 55mm Weight: 175g
