à¤Ã×èͧÇÑ´áÅФǺ¤ØÁ¡êÒ«¤ÒÃìºÍ¹ä´ÍÍ¡ä«´ì ẺµÔ´¼¹Ñ§ ¾ÃéÍÁ¨ÍÀÒ¾ Wall Mount CO2 Temperature Monitor & Controller AMT75 (Main Unit) & AMT75R (Remote Unit) à¤Ã×èͧÇÑ´áÅФǺ¤ØÁ¡êÒ«¤ÒÃìºÍ¹ä´ÍÍ¡ä«´ì AMT75 (Main Unit) & AMT75R (Remote Unit) Wall Mount CO2 Temperature Monitor & Controller AMT75 (Main Unit) & AMT75R (Remote Unit) Features: Dual Beam NDIR (Non-Dispersive Infrared) technology is used to measure CO2 concentration up to 50,000ppm. With the SEU (Sensor Unit, Order Number AMT75) and RDU (Remote Display Unit, Order Number AMT75R), it can connect up to 3 RDU for safety notices. Large digital LCD display clearly indicates the ambient CO2 Concentration and Temperature. Relay output can automatically control a fan to ventilate confined spaces. Audible and visual alarm indications. IP54 Water Proof Protection of SEU (Sensor Unit) except backside when installed on the wall. Installation Instruction Installation Instruction Specifications - CO2: Measurement Range 0~50,000ppm (5%) display Display Resolution 10ppm @0~10,000ppm, 100ppm @10,001ppm~50,000ppm Accuracy ±100ppm or ±5% of reading, whichever is greater Repeatability ±20ppm @400ppm Annual Drift <20ppm/Year @400ppm Temperature Dependence ±0.2% of reading per °C or ±2ppm per °C, whichever is greater, referenced to 25°C Pressure Dependence 0.13% of reading per mmHg Response Time <60 seconds="" for="" 90="" response="" to="" step="" change="" span=""> AL1 (First Alarm Level) 5000ppm, 1 / 1.5 / 2 % , Default AL1= 1.5% AL2 (Second Alarm Level) 1.5 / 2 / 2.5/ 3 / 3.5 / 4 %, Default AL2= 3% Warm-Up Time <60 seconds="" at="" 22="" c="" span=""> Sound Alarm 80db@10cm Specifications - Power Supply & Relay Output Power Supply AC adapter 110/220 VAC AC Input Voltage 100 ~ 240 VAC Frequency 50 / 60 Hz Power Requirement 1 W maximum @ 115 VAC 60 Hz; 2 W maximum @ 230 VAC 50 Hz AC/DC Output Voltage 6VDC Power 3.0 W Peak Input Current 0.5 A from 6VDC Relay Output 30VDC or 250VAC, max 2A, SPST, Normally Open Specifications - Temperature Temperature Range: 0°C to 50°C ( 32°F to 122°F) Display Resolution: 0.1°C (0.1°F) Display Options: °C / °F Accuracy: ±1°C(±2°F) when CO2 concentration is below first alarm level Response Time: 20-30 minutes (case must equalize with environment) Operating Conditions: Operating Temperature: 0°C to 40°C (32°F to 104°F), 0-95% RH, non-condensing Storage Temperature: -20 to 60°C (-4 to 140°F) Dimensions: AMT75: 124.8 x 167.7 x 46.57mm (4.91 x 6.6 x 1.83 inch) AMT75 AMT75R CO2 Controller CO2 Meter TLEAD à¤Ã×èͧÇÑ´¤ÒÃìºÍ¹ä´ÍÍ¡ä«´ì
