à¤Ã×èͧÇÑ´¤ÇÒÁÊÑèè¹ÊÐà·×͹ > VM-6360 à¤Ã×èͧÇÑ´¤ÇÒÁÊÑè¹ÊÐà·×͹ VM-6360 Vibration Meter Features In accordance with ISO2954, used for periodic measurements, to detect out-of-balance, misalignment and other mechanical faults in rotating machines. Specially designed for easy on site vibration measurement of all rotating machinery for quality control, commissioning, and predictive maintenance purposes. Individual high quality accelerometer for accurate and repeatable measurements Bearing condition monitoring function LCD digital display Light weight and easy to use Wide frequency range (10Hz. to 10k Hz.) in acceleration mode Automatic power shut off to conserve power. Specifications Velocity, Acceleration and Displacement RPM and Frequency Velocity : 0.01 - 40.00 cm/s True RMS 0.000 - 16.00 inch/s Acceleration : 0.1 - 40.00 m/s2 equivalent peak 0.3 - 1312 ft/s2 Displacement : 0.001 - 4.000 mm 0.04 - 160.0 mil, equivalent pk - pk RPM (r / min) : 60 - 99,990 r/min Readings should be multiplied by 10 if the display show '10'. Frequency : 1 - 20 k Hz LCD display : 4 digits, 18mm LCD Transducer : Piezoelectric accelerometer Parameters measured : Measuring range Frequency range for measuring Acceleration : 10Hz. to 1k Hz. in '1' mode Velocity : 10Hz. to 1kHz. Displacement : 10Hz. to 1kHz. 10Hz. to 10kHz in '10' mode for bearing condition checking Accuracy : + / - 5% n + 2 digits Metric / Imperial conversion Output : AC Output 2.0V peak full scale (load resistance : above 10k) Power supply : 4 x 1.5 AAA size batteries (not included) Operating temperature : 0 - 50°C Operating Humidity : below 90% RH Item dimension : 124 x 62 x 30mm / 4.9 x 2.4 x 1.2 inch Item weight : 120g (not including batteries Frequency Response: Acceleration (PK): Mode 1: 10 Hz to 1kHz Mode 2: 10 Hz to 10kHz (bearing faults) Velocity (True RMS): 10 Hz to 1kHz Displacement (PK-PK): 10 Hz to 1kHz Measurable Range: Acceleration (PK): 0.02 ~ 20g (0.2 ~ 199.9 mm/ss) Velocity (True RMS): 0.1 ~ 8 in/sec (0.2 ~ 199.9mm/s) Displacement (PK-PK) : 0.04 ~ 80mil (1 ~ 1999um ) RPM: 5 ~ 99,999 (readings multiplied by 10 if display shows '10' Power: 4, 1.5V AAA (UM-4) batteries Auto Power Off: Yes Max Hold: Yes Low Battery Indicator: Yes Overall vibration accuracy: 5% Operating Temperature: 0° C to +50° C (32° F to +122° F) Display Large, 4 Digit LCD Size: 124mm x 62mm x 30mm (4.88in x 2.44in x 1.18in ) Weight: 120g (0.25 lb) without batteries One set of item included 1pc Vibration meter (main unit) 1pc Powerful rare earth magnet 1pc Accelerometer 1pc stinger probe (cone) 1pc stinger probe (ball) 1 instruction booklet Packed the full set into a carry case (case as picture shown) HITECH Virbration Meter VM-6360 à¤Ã×èͧÇÑ´¤ÇÒÁÊÑè¹ÊÐà·×͹
