â·ÃÊͺ¶ÒÁÃÒ¤Ò ntelliTone 100 Toner and Probe Kit Includes: IntelliTone 100 Toner and 100 Probe, coax F connector adapter, RJ11 and RJ 45 patch cables, test leads with alligator clips, lanyards, owners CD and quick start guide, and (2) 9 volt batteries à¤Ã×èͧÇÑ´ÊÒÂÊÑ­­Ò³ MT-8200-50A Fluke Networks MT-8200-50A IntelliTone 100 Kit Features: Digital cable-sensing toner and probe for identifying cables in bundled voice, data, and video installations Safely and effectively traces cables hidden in floors, ceilings, walls, and elsewhere--even on active networks Decisively rejects noise and false signals while correctly isolating coaxial and bare wires Diagnoses and troubleshoots telecom/data services; visual and audible signal strength indicators Toner measures 2.94 x 5.54 x 1.2 inches (W x H x D); probe measures 8.73 x 1.88 x 1.26 inches Digital and analog tone generator and probe kit locates and traces data cabling on active networks and voice, audio, and video cabling on inactive networks Identifies the type of service and tests for voltage, polarity, ring, and continuity F-type connector supports VDV cable types including RJ45, RJ11, coaxial, and bare wire, and banana jacks accommodate test leads Four distinct cadences for isolating individual wire pairs Kit includes RJ11-to-RJ11 and RJ45-to-RJ45 patch cords, a test lead set with banana jacks to alligator clips, a female-to-female F-type connector adapter, a 9V alkaline battery, a product manuals CD, and instructions GENERAL SPECS Operating temperature 32 °F to 104 °F (0 °C to 40 °C) Storage temperature -4 °F to +140°F (-20 °C to °C) Operating relative humidity (% RH without condensation) 95 % (50 °F to 95 °F; 10 oC to 35 °C) 75 % (95 °F to 104 °F; 35 °C to 40 °C) Uncontrolled < 50 °F (< 10 °C) Vibration Random, 2 g, 5 Hz-500 Hz Shock 1 m drop test with and without module Safety EN 61010-1 1st Edition Amendments 1, 2 Altitude 3000 m EMC EN 61326-1 Battery type and life 9 V alkaline (NEDA 1604A or IEC 6LR61); 20 hours typical Applications Copper cabling media including; 75 or 50 Ohm Coaxial cable; Two Conductor control, security, generic cabling. 10 Base-T or 10/100 Base-T datacom networks. POTS telecom service and UTP cable. Shielded Twisted Pair supported in Cablemap function of the IntelliTone 200. TONER SPECS Dimensions 5.54 in x 2.94 in x 1.25 in (14.1 cm x 7.5 cm x 3.2 cm) Display LED Control Thumbwheel switch Toner interface Main Mod8 port for tone generation on all 4 pairs of UTP / STP cabling. F Connector for coaxial cabling Banana Jack Plugs (2) - two conductor wiring Toner frequency IntelliTone™ signal: encoded digital signal Analog SmartTone signal: 500 - 1200Hz, 4 songs Talk battery voltage 6 V into 600 W Ouptut power 5 V p-p Voltage protection 100V Auto power down Turns off automatically after 2 1/2 hours of inactivity PROBE SPECS Dimensions 8.73 in x 1.88 in x 1.26 in (22.2 cm x 4.8 cm x 3.2 cm) Display (8) LED indicators, Synch LED indicator Audio IntelliTone: Microprocessor controlled audio files Analog: Detected toner signal Control Thumbwheel switch, volume control wheel Tone detection Detects IntelliTone™ digital signal for Locate, Isolate, and CableMap Detects analog SmartTone signal (500-1200Hz) and other analog toners. Toner interface Main Mod8 port for cablemap on all 4 pairs of UTP / STP cabling. Auto power down Turns off automatically after 1 hour of inactivity Cable Tester Fluke Micromapper MT-8200-50A à¤Ã×èͧ·´ÊͺÊÒÂÊÑ­­Ò³
